EZHONG EZW11S-120*3200 PLATE COIL MACHINE IN WIND TOWERS

EZHONG's EZW11S-120*3200 plate coil machine represents a breakthrough in wind tower manufacturing technology, specifically engineered for producing the massive cylindrical sections that form the backbone of modern wind turbines. This advanced three-roll asymmetric plate rolling machine features a 120mm maximum plate thickness capacity and 3200mm rolling width, making it the ideal solution for wind tower fabrication facilities requiring high-precision rolling of heavy-gauge steel plates. The machine's sophisticated hydraulic control system enables precise pre-bending operations and consistent rolling performance, essential for creating the perfectly cylindrical tower sections that must meet stringent dimensional tolerances. Wind tower manufacturers worldwide choose EZHONG's plate coil machines for their reliability, precision, and ability to handle the demanding requirements of renewable energy infrastructure production.

Wind Tower Manufacturing Plant

Comprehensive view of a modern wind tower manufacturing plant equipped with EZHONG's EZW11S-120*3200 plate coil machine as the centerpiece of the production line. This facility demonstrates the integration of advanced rolling technology with material handling systems, welding stations, and quality control equipment necessary for high-volume wind tower production. The plant's layout optimizes workflow efficiency, enabling the transformation of flat steel plates into precisely formed cylindrical tower sections ready for assembly into complete wind turbine towers.

Plate Rolling Process Detail

Detailed view of the EZW11S-120*3200 machine rolling thick steel plates into tower section components. The three-roll asymmetric configuration provides superior control over the rolling process, with the upper roll applying downward pressure while the two lower rolls support and guide the material. Advanced position sensors and hydraulic controls maintain precise roller alignment throughout the operation, ensuring consistent radius and eliminating flat spots or dimensional variations. This level of precision is critical for wind towers, where even minor deviations can compromise structural integrity or complicate tower assembly in the field.

Main Parameter Table of EZW11S-120*3200 Plate Coil Machine

ITEM Unit DATA
Specifications mm 120×3200
Maximum thickness of bending plate mm 120
Maximum working width mm 3200
Full-load minimum workpiece diameter mm 4500
Plate yield limit MPa 245
Rolling speed m/min ≤3.5
